Hydraulic Conversion Kit: 55-57 Chevrolet: Line w/GM QD Fitting: No Bearing
Hydraulic Conversion Kit -Ideal For Cars That Have Aging Mechanical Linkage Or Need Extra Space Due To A Motor Swap Or Other Changes, A Mcleod Hydraulic Kit Is Designed With The Very Best Components For Ease Of Install And Great Life. An Additional Benefit When Installing This Mcleod Hydraulic Kit Is The Self-Adjusting Bearing Feature. No More Adjusting The Clutch Every 4 — 6 Months. The Hydraulic Kit Will Allow The Bearing To Self Adjust When The Disc Wears Throughout It Is Life Cycle. Include Master Cylinder And Line. Hydraulic Bearing Must Be Purchased Separately
- • 3/4" bore master cylinders.
• Precision-machined from high-strength aluminum.
• Easy Installation.
• Includes Master Cylinder and Line.
• No Hydraulic Bearing.
Information:
FIREWALL KIT ONLY! The Kit does not come with a hydraulic slave cylinder.
Application Summary:
| Year |
Make/Model |
| 1955-1957 |
Chevrolet Bel Air |
| 1955-1957 |
Chevrolet One-Fifty Series |
| 1955-1957 |
Chevrolet Two-Ten Series |
| Attributes |
| Application |
1955-57 Chevrolet, 1955-57 Chevy |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Fitting Connection |
1997-2004 GM Male Quick Disconnect |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Hose Type |
Stainless Steel AN4 to GM Male Quick Disconnect Fitting |
| Hoses Included |
Yes |
| Hydraulic Bearing Included |
No |
| Hydraulic Slave Included |
No |
| Life Cycle Status Code |
Available to Order |
| Make |
Chevrolet |
| Master Cylinder Bore Size |
.750In. |
| Master Cylinder Bore Size (in.) |
0.750 |
| Master Cylinder Stroke |
1.2In. |
| Master Cylinder Stroke (in.) |
1.200 |
| Master Cylinder Usage |
Clutch |
| Mounting Brackets Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| NOTE: |
This kit is intended to work with McLeod Racing 1300 & 1400 series internal hydraulic bearings (Sold Separately) Call McLeod Tech for more info at 714-630-2764 |
| Notes |
Firewall Kit Only. Hydraulic Bearing (sold separately). Can also be used with a 1998-2002 Camaro or 1997-2004 Corvette factory bearing. |
| Quantity |
Sold as a kit. |
| Reservoir Included |
Yes |
| SDR Required Flag |
N |
| SDS Sheet Number |
N/A |
| Slave Cylinder Included |
No |
| Warranty Time |
90 |
| GTIN |
00887753011510 |
