Hydraulic Conversion Kit: 1962-1967 Chevrolet Nova: Line w/AN-4 Fitting: No Bearing
Hydraulic Conversion Kit -Ideal For Cars That Have Aging Mechanical Linkage Or Need Extra Space Due To A Motor Swap Or Other Changes, A Mcleod Hydraulic Kit Is Designed With The Very Best Components For Ease Of Install And Great Life. An Additional Benefit When Installing This Mcleod Hydraulic Kit Is The Self-Adjusting Bearing Feature. No More Adjusting The Clutch Every 4 — 6 Months. The Hydraulic Kit Will Allow The Bearing To Self Adjust When The Disc Wears Throughout It Is Life Cycle. Include Master Cylinder And Line. Hydraulic Bearing Must Be Purchased Separately
- • 3/4" bore master cylinders.
• Precision-machined from high-strength aluminum.
• Easy Installation.
• Includes Master Cylinder and Line.
• No Hydraulic Bearing.
Information:
FIREWALL KIT ONLY! The Kit does not come with a hydraulic slave cylinder.
Application Summary:
| Year |
Make/Model |
| 1962-1967 |
Chevrolet Chevy II |
| Attributes |
| Application |
1962-67 Chevrolet Nova, 1962-67 Nova |
| Country of Origin (Primary) |
US |
| Emission Code |
Legal US |
| Fitting Connection |
AN-4 |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Hoses Included |
Yes |
| Hydraulic Bearing Included |
No, No |
| Hydraulic Line Type |
Stainless Steel Braided AN-4 |
| Life Cycle Status Code |
Available to Order |
| Make |
Chevrolet |
| Master Cylinder Bore |
.750In. |
| Master Cylinder Bore Size (in.) |
0.750 |
| Master Cylinder Stroke |
1.2In. |
| Master Cylinder Stroke (in.) |
1.200 |
| Master Cylinder Usage |
Clutch |
| Mounting Brackets Included |
Yes |
| NAFTA Preference Criterion Code |
B |
| NOTE 2: |
This firewall kit was designed to work with 1962-1967 Nova Manual Pedal Box Assemblies Only. |
| NOTE: |
This is the firewall kit only. This kit was designed to be used with a McLeod Racing 1300 or 1400 series internal hydraulic bearing. (Sold Separately) |
| Notes |
Firewall Kit Only. Hydraulic Bearing (sold separately). Works with 1962-67 Nova manual pedal box assemblies only. |
| Quantity |
Sold as a kit. |
| Reservoir Included |
Yes |
| SDR Required Flag |
N |
| SDS Sheet Number |
N/A |
| Slave Cylinder Included |
No |
| Warranty Time |
90 |
| GTIN |
00887753011220 |
