4400 Series Truck Pull: Ford 1963-95 SBF 289/302/351: 1-3/8 X 10 Spline: 164T
The 4400 Series clutch system from McLeod is ideal for Truck Pulling and high horsepower sand drag applications. Recommended for non-shifting motorsport applications. This series features a Borg & Beck/Long pressure plate assembly, unique to McLeod that also includes counterweights providing additional high RPM lockup capacity. Steel flywheels are included with these systems along with low coefficient friction sintered iron discs. Due to the pin style drive on the floater plate, these multi disc clutches are not suitable for street applications as they will be very noisy at idle and low RPM.
- • Borg & Beck long style pressure plate w/counterweights.
• High RPM lock-up capacity.
• Sintered iron discs.
• Steel Flywheel Included.
Information:
Counter Weight Kit if Required 563333 (sold separately)
Application Summary:
| Year |
Make/Model |
| 1966-1995 |
Ford Bronco |
| 1969-1983 |
Ford E-100 Econoline |
| 1975-1983 |
Ford E-100 Econoline Club Wagon |
| 1975-1989 |
Ford E-150 Econoline |
| 1975-1989 |
Ford E-150 Econoline Club Wagon |
| 1975-1982 |
Ford E-250 Econoline |
| 1984 |
Ford E-250 Econoline |
| 1975-1982 |
Ford E-250 Econoline Club Wagon |
| 1984 |
Ford E-250 Econoline Club Wagon |
| 1975-1989 |
Ford E-350 Econoline |
| 1977-1984 |
Ford E-350 Econoline Club Wagon |
| 1969-1975 |
Ford F-100 |
| 1980-1983 |
Ford F-100 |
| 1975-1995 |
Ford F-150 |
| 1969-1974 |
Ford F-250 |
| 1977-1995 |
Ford F-250 |
| 1972-1995 |
Ford F-350 |
| 1972 |
Ford P-350 |
| 1976 |
Ford P-350 |
| 1976 |
Ford P-400 |
| 1976-1977 |
Ford P-500 |
| 1965-1971 |
Ford Ranchero |
| 1975-1977 |
Ford Ranchero |
| Attributes |
| Alignment Tool Included |
Yes |
| Application |
Truck Pull |
| Casting Material (Donut) |
Billet Steel |
| Clutch Disc Quantity |
2 |
| Clutch Usage |
Performance |
| Counter Weight Kit |
164T |
| Counter Weight Kit if Required |
563333 (sold separately) |
| Counter-weighted Lever |
Adjustable |
| Counterweight Assist |
Yes |
| Country of Origin (Primary) |
US |
| Crankshaft to Flywheel Bolt Quantity |
6-bolt |
| Disc Diameter |
Billet Aluminum with Steel Heat Shield |
| Disc Diameter (in.) |
10.500 |
| Disc Material |
Sintered Iron, Adjustable |
| Disc Style |
Full face |
| Emission Code |
Legal US |
| Engine 1 |
1963-1995 SBF 289/302/351 |
| Engine 2 |
0 Balance |
| Engine 3 |
563333 (Sold Separately) |
| Engine Balance |
Billet Steel, Internal |
| Flywheel Included |
Yes |
| Flywheel Material |
1-3/8 x 10, Billet steel |
| Hardware Included |
Yes |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Hub Style |
Solid |
| Input Shaft Diameter (in.) |
1.375 |
| Input Spline Quantity |
10 |
| Input-shaft Spline |
5191 Sintered Iron |
| Lever Material |
Billet Steel |
| Life Cycle Status Code |
Available to Order |
| Make |
Ford |
| NAFTA Preference Criterion Code |
B |
| Pilot Bushing Included |
No |
| Pressure Plate Style |
Long |
| Quantity |
Sold as a kit. |
| Ring Gear |
10.5In. |
| Ring Gear Tooth Quantity |
164-tooth |
| SDR Required Flag |
N |
| SDS Sheet Number |
N/A |
| Throwout Bearing Included |
No |
| Warranty Time |
90 |
| GTIN |
00887753677792 |
