Original Street Twin: Aluminum: GM 1998-02 F-Body: 1-1/8 x 26: 168T: w/Master Cylinder
Original Street Twin - Rated up to 1200 HP, this clutch system is perfect for high horsepower street cars applications. Designed for vehicles with superchargers, turbochargers, NOS or big cubic inch engines. Available with either organic or ceramic discs. Performance aluminum or steel flywheel included with the Original Street Twin system.
- • Street Twin.
• Street Friendly.
• Ceramic or Organic Discs.
• Strap Drive.
• Flywheel Included.
Application Summary:
| Year |
Make/Model |
| 1998-2002 |
Chevrolet Camaro |
| 1998-2002 |
Pontiac Firebird |
| Attributes |
| Alignment Tool Included |
Yes |
| Application |
1998-2002 Camaro, Firebird |
| Clutch Disc Quantity |
2 |
| Clutch Usage |
Performance |
| Counterweight Assist |
No |
| Country of Origin (Primary) |
US |
| Crankshaft to Flywheel Bolt Quantity |
6-bolt |
| Disc Diameter |
10.5In. |
| Disc Diameter (in) |
10.5" |
| Disc Diameter (in.) |
10.500 |
| Disc Material |
Organic |
| Disc Style |
Full Face, Full face |
| Emission Code |
Legal US |
| Engine Balance |
Internal |
| Flywheel Included |
Yes, Yes |
| Flywheel Material |
Aluminum, Billet aluminum |
| Hardware Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Horsepower Rating |
1200, 1200 |
| Hub |
Solid |
| Hub Style |
Solid |
| Input Shaft Diameter (in.) |
1.125 |
| Input Spline Quantity |
26 |
| Inputshaft Diameter & Splline |
1-1/8 x 26 |
| Life Cycle Status Code |
Available to Order |
| Make |
Chevrolet/Ponitac |
| NAFTA Preference Criterion Code |
B |
| Note |
Comes with 13/16In. Bore Master Cylinder |
| NOTE 2: |
CENTERBORE/CRANK BOSS: Because of standard variances in OEM and Aftermarket manufacturing tolerances, the flywheel to crankshaft boss fit may have variations from slip-fit to slight interference. Interference at the crankshaft “boss” can be corrected by heating the flywheel to temporarily to expand the center bore for correct mounting. Caution, flywheel will be hot, handle with care. |
| NOTE: |
Comes with 13/16In. Bore Master Cylinder |
| Number of Discs |
Double |
| Pilot Bushing Included |
No, No |
| Pilot Bushing Material |
N/A |
| Pressure Plate Style |
Diaphragm, Diaphragm |
| Quantity |
Sold as a kit. |
| Ring Gear |
168T |
| Ring Gear Tooth Quantity |
168-tooth |
| SDR Required Flag |
N |
| SDS Sheet Number |
N/A |
| Spline |
1-1/8 x 26 |
| Throwout Bearing Included |
No, No |
| Warranty Time |
90 |
| GTIN |
00887753675347 |
