RXT 1100HP Twin Disc Clutch: Aluminum Flywheel: Ford 1996-10 4.6L 8 Bolt Crank: 1-1/16 x 10: 164T
Intended for the high horsepower street/strip fan, the McLeod RXT Street twin clutch kit is able to handle 1100hp, this clutch can handle almost any horse-power you can throw at it and still remain street-able. Ceramic lined clutch discs will provide smooth engagement with a soft pedal effort to make this clutch kit ideal for the street performance enthusiast. This clutch is perfect for the person that wants the best of both worlds. You want to drive to the track then rip off a bunch of ¼ mile passes then drive back home, the RXT is what you’ll need! This series of clutch comes in 3 different configurations to best suit your needs. Adapter ring version. Another McLeod Racing exclusive. We build a twin disc clutch using a Patented Approved adapter ring to bolt to your supplied flywheel. Complete Unit with Dedicated Flywheel. No need to search for the clutch as one number and the flywheel as another number. McLeod Racing has you covered with one part number and a complete dedicated unit ready to plug and play. You have the choice of running a Billet Steel flywheel for your street applications or a Billet Aluminum flywheel for your track cars.
- • Lighter than Stock Pedal Feel.
• Metallic Facings for Increased Holding Power.
• Excellent Release Qualities.
• Bolts to Most Flywheels.
• Available with Aluminum or Steel Flywheel.
Application Summary:
| Year |
Make/Model |
| 2005-2010 |
Ford Mustang |
| Attributes |
| Alignment Tool Included |
Yes, Yes |
| Application |
1996-2010 4.6,5.4L Ford Modular with 8 Bolt Crank. 1-1/16 x 10 Spline. |
| Clutch Disc Quantity |
2 |
| Clutch Usage |
Performance, Performance |
| Country of Origin (Primary) |
US |
| Crankshaft to Flywheel Bolt Quantity |
8-bolt, 8-bolt |
| Disc Configuration |
Twin |
| Disc Diameter (in.) |
9.688 |
| Disc Material |
Ceramic, Ceramic |
| Disc Size |
9.687In. |
| Disc Style |
Segmented, Segmented |
| Emission Code |
Legal US |
| Engine Balance |
Internal |
| Flywheel Included |
Yes, Yes |
| Flywheel Material |
Aluminum, Billet aluminum |
| Hardware Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Horsepower Rating |
1000 Hp/Tq at the crank., 1000 |
| Hub Style |
Solid, Solid |
| Input Shaft Diameter (in.) |
1.063 |
| Input Spline Quantity |
10 |
| Inputshaft Spline |
1-1/16 x 10 |
| Life Cycle Status Code |
Available to Order |
| Make |
Ford |
| NAFTA Preference Criterion Code |
B |
| NOTE 2: |
CENTERBORE/CRANK BOSS: Because of standard variances in OEM and Aftermarket manufacturing tolerances, the flywheel to crankshaft boss fit may have variations from slip-fit to slight interference. Interference at the crankshaft “boss” can be corrected by heating the flywheel to temporarily to expand the center bore for correct mounting. Caution, flywheel will be hot, handle with care. |
| NOTE: |
Will fit all 1996-2010 Ford Mustang Base Model and GT with the use of a aftermarket 8 bolt crank. Further questions please call McLeod Tech Line at 714-630-2764. |
| Pilot Bearing/Bushing Included |
No |
| Pilot Bushing Included |
No |
| Pressure Plate Style |
Diaphragm, Diaphragm |
| Quantity |
Sold as a kit., Sold as a kit. |
| Ring Gear Count |
164 |
| Ring Gear Tooth Quantity |
164-tooth, 164-tooth |
| SDR Required Flag |
N |
| SDS Sheet Number |
N/A |
| T.O. Bearing Included |
No |
| Throwout Bearing Included |
No |
| Warranty Time |
90 |
| GTIN |
00887753019318 |
