RST 800HP Twin Disc Clutch: Steel Flywheel: GM 1997-13 LS-X 6 Bolt Crank: 1-1/8 x 10: 168T
Intended for the high horsepower street fan, the McLeod RST twin disc clutch kit is an economically priced twin disc clutch kit. Able to handle 800hp, this clutch can handle almost any horse-power you can throw at it and still remain street-able. Organic lined clutch discs will provide smooth engagement with a soft pedal effort to make this clutch kit ideal for the street only performance enthusiast. This unit is not intended for competition use! Look to our RXT and RXT HD for those applications. This series of clutch comes in 3 different configurations to best suit your needs. Adapter ring version. Another McLeod Racing exclusive. We build a twin disc clutch using a Patented Approved adapter ring to bolt to your supplied flywheel. Complete Unit with Dedicated Flywheel. No need to search for the clutch as one number and the flywheel as another number. McLeod Racing has you covered with one part number and a complete dedicated unit ready to plug and play. You have the choice of running a Billet Steel flywheel for your street applications or a Billet Aluminum flywheel for your track cars.
  • • Lighter than Stock Pedal Feel. • Organic Facings for Smooth Engagement. • Excellent Release Qualities. • Bolts to Most Flywheels. • Available with Aluminum or Steel Flywheel.

Application Summary:

Year Make/Model
2001-2006 Chevrolet Silverado 1500
2007 Chevrolet Silverado 1500 Classic
2002 Chevrolet Silverado 1500 HD
2001-2004 Chevrolet Silverado 2500
2001-2006 Chevrolet Silverado 2500 HD
2007 Chevrolet Silverado 2500 HD Classic
2001-2006 Chevrolet Silverado 3500
2007 Chevrolet Silverado 3500 Classic
2001-2006 GMC Sierra 1500
2007 GMC Sierra 1500 Classic
2001-2004 GMC Sierra 2500
2001-2006 GMC Sierra 2500 HD
2007 GMC Sierra 2500 HD Classic
2001-2006 GMC Sierra 3500
2007 GMC Sierra 3500 Classic
Attributes
Alignment Tool Included Yes, Yes
Application GM LS-X 6 Bolt Crank
Clutch Disc Quantity 2
Clutch Usage Performance, Performance
Country of Origin (Primary) US
Crankshaft to Flywheel Bolt Quantity 6-bolt, 6-bolt
Disc Diameter (in) 9.6875In.
Disc Diameter (in.) 9.688
Disc Material Organic, Organic
Disc Style Full Face, Full face
Emission Code Legal US
Engine Balance Internal
Flywheel Included Yes, Yes
Flywheel Material Steel, Billet steel
Hardware Included Yes, Yes
Harmonized Tariff Code (Schedule B) 8708935000
Hazardous Material Code N
Horsepower Rating 800, 800
Hub Solid
Hub Style Solid, Solid
Input Shaft Diameter (in.) 1.125
Input Spline Quantity 10
Inputshaft Diameter & Splline 1-1/8 x 10
Life Cycle Status Code Available to Order
Make Chevrolet
NAFTA Preference Criterion Code B
NOTE: CENTERBORE/CRANK BOSS: Because of standard variances in OEM and Aftermarket manufacturing tolerances, the flywheel to crankshaft boss fit may have variations from slip-fit to slight interference. Interference at the crankshaft “boss” can be corrected by heating the flywheel to temporarily to expand the center bore for correct mounting. Caution, flywheel will be hot, handle with care.
Pilot Bushing Included No, No
Pressure Plate Style Diaphragm, Diaphragm
Quantity Sold as a kit., Sold as a kit.
Ring Gear Tooth Quantity 168-tooth, 168-tooth
SDR Required Flag N
SDS Sheet Number N/A
Throwout Bearing Included No, No
Warranty Time 90
GTIN 00887753675415
