SPECIAL ORDER: Mag Force: 2 Disc: Pin Drive: Ford 1963-95 SBF 289/302/351: 1-1/8 x 10 Spline: 164T Aftermarket Transmission
Mag Force - These Clutches Are the Perfect Choice for Racers Looking for A Lightweight, High Torque Capacity Unit. They Are Designed to Be Used for Oval Track, Road Racing and Dry Lakes Applications. These Units Are Offered in Single Disc (500Ft Tq) Double Disc (900 Ft Tq) And Triple Disc (1500 Ft Tq) Configurations to Meet the Harshest Needs in The Industry. These Units Rely on A Pin Drive Actuation System Where the Floater Plate Slides On 6 Evenly Spaced Pins for Quick Release in A Racing Application. Our Mag Force Units Also Offer Bolt on External Balance Weights for Most Applications.
Mag Force - These Clutches Are the Perfect Choice for Racers Looking for A Lightweight, High Torque Capacity Unit. They Are Designed to Be Used for Oval Track, Road Racing and Dry Lakes Applications. These Units Are Offered in Single Disc (500Ft Tq) Double Disc (900 Ft Tq) And Triple Disc (1500 Ft Tq) Configurations to Meet the Harshest Needs in The Industry. These Units Rely on A Pin Drive Actuation System Where the Floater Plate Slides On 6 Evenly Spaced Pins for Quick Release in A Racing Application. Our Mag Force Units Also Offer Bolt on External Balance Weights for Most Applications.
- • Ceramic Discs. • Pin or Strap Drive. • Oval Track, Road Racing and Dry Lakes usage. • Single Disc (500Ft Tq) • Double Disc (900 Ft Tq) • Triple Disc (1500 Ft Tq
Information:
SPECIAL ORDERApplication Summary:
| Year | Make/Model |
|---|---|
| 1963 | Ford 300 |
| 1966-1995 | Ford Bronco |
| 1964-1972 | Ford Custom |
| 1973 | Ford Custom 500 |
| 1969-1983 | Ford E-100 Econoline |
| 1975-1983 | Ford E-100 Econoline Club Wagon |
| 1975-1989 | Ford E-150 Econoline |
| 1975-1989 | Ford E-150 Econoline Club Wagon |
| 1975-1982 | Ford E-250 Econoline |
| 1984 | Ford E-250 Econoline |
| 1975-1982 | Ford E-250 Econoline Club Wagon |
| 1984 | Ford E-250 Econoline Club Wagon |
| 1975-1989 | Ford E-350 Econoline |
| 1977-1984 | Ford E-350 Econoline Club Wagon |
| 1969-1975 | Ford F-100 |
| 1980-1983 | Ford F-100 |
| 1975-1995 | Ford F-150 |
| 1969-1974 | Ford F-250 |
| 1977-1995 | Ford F-250 |
| 1972-1995 | Ford F-350 |
| 1963-1969 | Ford Fairlane |
| 1978-1979 | Ford Fairmont |
| 1964-1970 | Ford Falcon |
| 1963-1967 | Ford Galaxie |
| 1968-1973 | Ford Galaxie 500 |
| 1975-1980 | Ford Granada |
| 1966-1969 | Ford GT40 |
| 1966-1973 | Ford LTD |
| 1983 | Ford LTD |
| 1971-1977 | Ford Maverick |
| 1964-1973 | Ford Mustang |
| 1979 | Ford Mustang |
| 1982-1995 | Ford Mustang |
| 1975-1978 | Ford Mustang II |
| 1972 | Ford P-350 |
| 1976 | Ford P-350 |
| 1976 | Ford P-400 |
| 1976-1977 | Ford P-500 |
| 1965-1971 | Ford Ranchero |
| 1975-1977 | Ford Ranchero |
| 1968-1974 | Ford Torino |
| Attributes | |
| Alignment Tool Included | Yes, Yes |
| Balance | Internal Balance |
| Clutch Disc Quantity | 2 |
| Clutch Usage | Performance |
| Counter Weight Kit if Required | 563333 (sold separately) |
| Counterweight Assist | No |
| Country of Origin (Primary) | US |
| Crankshaft to Flywheel Bolt Quantity | 6-bolt |
| Disc Diameter | 8In. |
| Disc Diameter (in.) | 8.000 |
| Disc Material | Sintered Iron, Sintered Iron |
| Disc Style | Segmented, Full face |
| Emission Code | Legal US |
| Engine | 1964-1995 SBF |
| Engine Balance | For External Balance use 563333 Kit, Internal |
| Flywheel Included | Yes, Yes |
| Flywheel Material | Aluminum, Billet aluminum |
| Hardware Included | Yes, Yes |
| Harmonized Tariff Code (Schedule B) | 8708935000 |
| Hazardous Material Code | N |
| Hub Style | Solid |
| Input Shaft Diameter (in.) | 1.125 |
| Input Spline Quantity | 10 |
| Life Cycle Status Code | Available to Order |
| Make | Ford, Ford |
| NAFTA Preference Criterion Code | B |
| Note | Aftermarket Transmission |
| Notes | Aftermarket Transmission |
| Number of Discs | Double |
| Pilot Bushing Included | No, No |
| Pilot Bushing Material | N/A |
| Pressure Plate Style | Diaphragm |
| Quantity | Sold as a kit. |
| Racing Application | Road Race & Slalom Racing |
| Racing Application 2 | Drifting |
| Racing Application 3 | Dry Lakes (Bonneville) |
| Ring Gear | 164 tooth |
| Ring Gear Tooth Quantity | 164-tooth |
| SDR Required Flag | N |
| SDS Sheet Number | N/A |
| Spline | 1-1/8 x 10 |
| Throwout Bearing Included | No, No |
| Throwout Bearing Style | Standard |
| Warranty Time | 90 |
| GTIN | 00887753676412 |
