Mag Force: 2 Disc: Strap Drive: Ford 1996-17 8 Bolt: 1-1/16 x 10: 164T
Mag Force - These Clutches Are the Perfect Choice for Racers Looking for A Lightweight, High Torque Capacity Unit. They Are Designed to Be Used for Oval Track, Road Racing and Dry Lakes Applications. These Units Are Offered in Single Disc (500Ft Tq) Double Disc (900 Ft Tq) And Triple Disc (1500 Ft Tq) Configurations to Meet the Harshest Needs in The Industry. These Units Rely on A Pin Drive Actuation System Where the Floater Plate Slides On 6 Evenly Spaced Pins for Quick Release in A Racing Application. Our Mag Force Units Also Offer Bolt on External Balance Weights for Most Applications.
- • Ceramic Discs.
• Pin or Strap Drive.
• Oval Track, Road Racing and Dry Lakes usage.
• Single Disc (500Ft Tq)
• Double Disc (900 Ft Tq)
• Triple Disc (1500 Ft Tq
Application Summary:
| Year |
Make/Model |
| 1996-2001 |
Ford Mustang |
| 2003-2004 |
Ford Mustang |
| 2007-2009 |
Ford Mustang |
| Attributes |
| Additional Counter Weight Kit Required |
N/A |
| Alignment Tool Included |
Yes, Yes |
| Clutch Disc Quantity |
2 |
| Clutch Patterns |
Proprietery McLeod Mag Force |
| Clutch Usage |
Performance, Drifting,Land Speed, Road Race |
| Country of Origin (Primary) |
US |
| Crankshaft to Flywheel Bolt Quantity |
8-bolt |
| Disc Diameter |
8In. |
| Disc Diameter (in.) |
8.000 |
| Disc Material |
Sintered Iron, Sintered Iron |
| Disc Style |
Full face, Segmented |
| Emission Code |
Legal US |
| Engine |
1996-2017 4.6L/5.0L/5.4L Modular with 8 Bolt Crank |
| Engine Balance |
Neutral, Internal |
| Flywheel Included |
Yes |
| Flywheel Material |
Aluminum, Billet aluminum |
| Hardware Included |
Yes, Yes |
| Harmonized Tariff Code (Schedule B) |
8708935000 |
| Hazardous Material Code |
N |
| Hub Style |
Solid, Solid |
| Input Shaft Diameter (in.) |
1.063 |
| Input Spline Quantity |
10 |
| Life Cycle Status Code |
Available to Order |
| Make |
Ford |
| NAFTA Preference Criterion Code |
B |
| Number of Discs |
Double |
| Pilot Bushing Included |
No, No |
| Pilot Bushing Material |
N/A |
| Pressure Plate Style |
Diaphragm, Diaphragm |
| Quantity |
Sold as a kit. |
| Ring Gear |
164T |
| Ring Gear Tooth Quantity |
164-tooth |
| SDR Required Flag |
N |
| SDS Sheet Number |
N/A |
| Spline |
1-1/16 x 10 |
| Throwout Bearing Included |
No, Yes |
| Throwout Bearing Style |
Standard |
| Torque Rating |
900 Ft. Lbs. |
| Warranty Time |
90 |
| GTIN |
00887753315021 |
