RXT HD 1300HP Twin Disc Clutch: For use with Small Diameter Flywheel: Black Ring: 1-3/16 x 10 Spline
McLeod RXT HD – Rated up to 1300 HP, this twin disc clutch is Intended for the high horsepower street/strip fan. This clutch can handle serious horsepower and still remain street-able. Ceramic lined clutch discs will provide smooth engagement with a moderate pedal effort to make this clutch kit ideal for the street performance enthusiast. This clutch is perfect for the person that wants the best of both worlds. This clutch is perfect for the person that wants the best of both worlds. You want to drive to the track then rip off a bunch of ¼ mile passes then drive back home, the RXT HD is what you’ll need! This series of clutches comes in 3 different configurations to best suit your needs. Adapter ring version. Another McLeod Racing exclusive. We build a twin disc clutch using a patented approved adapter ring to bolt to your supplied flywheel. Complete unit with dedicated flywheel. No need to search for the clutch as one number and the flywheel as another number. McLeod Racing has you covered with one part number and a complete dedicated unit ready to plug and play. You have the choice of running a Billet Steel flywheel for your street applications or a Billet Aluminum flywheel for your track cars.
  • • Metallic Facings for Increased Holding Power. • Higher Clamp Load Pressure Plate. • Excellent Release Qualities. • Bolts to Most Flywheels. • Available with Aluminum or Steel Flywheel.

Application Summary:

Year Make/Model
1963 Chrysler 300
1963 Chrysler Newport
1964-1965 Dodge 880
1970-1971 Dodge Challenger
1966-1971 Dodge Charger
1965-1966 Dodge Coronet
1970-1971 Dodge Coronet
1965 Dodge Monaco
1963-1965 Dodge Polara
1968-1969 Plymouth Barracuda
1971 Plymouth Barracuda
1963-1967 Plymouth Belvedere
1969 Plymouth Belvedere
1970-1971 Plymouth Cuda
1963-1966 Plymouth Fury
1968-1971 Plymouth GTX
1968-1971 Plymouth Road Runner
1965-1967 Plymouth Satellite
1963-1964 Plymouth Savoy
Attributes
Alignment Tool Included Yes, Yes
Clutch Disc Quantity 2
Clutch Patterns 10In. & 10.5In. Long & 10In. Diaphragm, 10/10.5 in. Diaphragm/Long w/Shouldered Bolt
Clutch Usage Performance, Street/Track
Country of Origin (Primary) US
Disc Diameter 9-11/16In.
Disc Diameter (in.) 9.688
Disc Material Ceramic, Ceramic
Disc Style Segmented, Full Face/Multi Pad
Emission Code Legal US
Flywheel Fitment Fits 130 Tooth Flywheel, For use with Small Diameter Flywheel
Flywheel Included No, No
Hardware Included Yes, Yes
Harmonized Tariff Code (Schedule B) 8708935000
Hazardous Material Code N
Horsepower Rating 1200, 1200
Hub Style Solid, Solid
Input Shaft Diameter (in.) 1.188
Input Spline Quantity 18
Life Cycle Status Code Available to Order
Make Mopar, Chrysler
NAFTA Preference Criterion Code B
Number of Discs Double
OE Flywheel Size Small
Pilot Bushing Included No, No
Pilot Bushing Material N/A
Pressure Plate Style Diaphragm, Diaphragm
Quantity Sold as a kit.
SDR Required Flag N
SDS Sheet Number N/A
Spline 1 3/16In. x 18
Throwout Bearing Included No, No
Throwout Bearing Style Standard
Warranty Time 90
GTIN 00887753019097
